RCA 2102-1BKGA Betriebsanweisung

DECT 6.0 Multi Handset Cordless Phone Answering System User’s Guide Please read this manual before operating product for the first

10 • Do not use the product in places where there are explosive hazards. • Do not let small metal objects come into contact with the product. T

11 Overview of the base station 1 2 3 4 5 6 9 8 7 1 • Increase/decrease the speaker volume 2 • Messages counter 3 • Delete messa

12 Display Icons In standby mode, the icons shown on the main screen tell you what features are available on your handset. Icon Descriptions When t

13 Installing the Phone Installing the Handset Battery NOTE: You must connect the handset battery before use. CAUTION: To reduce the risk of fire

14 2. Plug one end of the telephone line cord into the TEL LINE jack on the back of the base and the other end into a modular jack. 3. Plug the

15 Set the date and time 1 P r e s s MENU. 2 S e l e c t [CLOCK] > [SET DATE/TIME], then press [OK] to confirm. 3 Press the numeric butto

16 Personalize the sounds Set the handset’s melody You can select from 10 melodies 1 Press MENU. 2 Select [PERSONAL SET] > [HANDSET TONES] &g

17 is 0000. The maximum length of the Master PIN is 8 digits. Note: If you forget your PIN code, you can reset it to its default 0000 using a handse

18 »» The handset displays a confirmation request. 3 Press [OK] to confirm. »» All settings are reset. Area Code 1. Press MENU. 2. Select [ADVAN

19 First ring If you have subscribed to the caller ID service with your service provider, your phone can suppress the first ring before the cal

2 Equipment Approval Information Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in compliance wi

20 3 Press [OK]. »» The most recent number is then dialed out . Call from the redial list 1 Press REDIAL. 2 Press the UP or DOWN key to select th

21 2 When the phone rings, press EXIT . Adjust the earpiece volume Press or to adjust the volume during a call. »» The earpiece volume is adjus

22 2 Select a handset number, then press [OK] to confirm. 3 Press EXIT when the other side answers your call. »» The call is now transferred

23 Press 2 once: a Press 8 two times: u Press 5 three times: l Press and hold [#PAUSE/RINGER] to switch between the uppercase and lowercase letters.

24 •• If your phonebook memory is full, the handset displays a notification message. Delete some records to add new ones. 1 Press MENU. 2 Sel

25 This feature is available if you have registered to the caller ID service with your service provider. Your phone can store up to 10 call records.

26 1 Press . 2 Select [CALL LIST], then press [OK] to confirm. »» The incoming call log is displayed. 3 Press [OK] to enter the options menu.

27 »» All records are deleted. Keypad lock You can lock the keypad to prevent accidental button presses. Lock the keypad 1 Press and hold [*/FORMAT]

28 Through the base 1 Press to turn on/off the answering machine in standby mode. Note ••When the answering machine is switched on, it answers incom

29 6 Press [OK] to stop recording or the recording stops after 2 minutes. »» You can listen to the newly recorded announcement on the handset. Note

3 2 Rights of the Telephone Company Should your equipment cause trouble on your line which may harm the telephone network, the telephone company shal

30 From the base • Start/Stop listening: Press . • Adjust the volume: Press + / -. • Skip backward: - When you listen to the messages, press to l

31 »» All old messages are permanently deleted. Note •• You can delete the read messages only. No deleted messages can be recovered. Call screening Y

32 1 Press MENU. 2 Select [ANSWER MACHINE] > [SETTINGS] > [REMOTE ACCESS], then press [OK] to confirm. 3 Select a new setting, then press

33 Master pin 0000 First ring On Conference On Dial mode Tone H/S ringer melody Melody 1 H/S ringer volume Level 3 H/S earpiece volume Volume

34 The handset on the charger does not charge. • Ensure the battery pack is inserted properly. • Ensure the handset is placed properly on the charg

35 Warranty Assistance Your sales receipt will be required to demonstrate proof of purchase in order to validate your warranty eligibility. You

36 • Call Customer Care at 1-877-722-4908. Please have your product with you and please have your model number and date code available when callin

37 GIVEN BY SUPREME POWER USA LLC, ITS AGENTS, EMPLOYEES, RETAIL DEALERS OR INDEPENDENT CONTRACTORS SHALL CREATE A GUARANTY OR IN ANY

38 Visit the RCA web site at www.rca4phones.com Please do not send any products to the Indianapolis address listed in this

4 • Connect the telecommunications equipment into an outlet on a circuit different from that to which the receiving antenna is connected. If these m

5 Table of Contents Equipment Approval Information...2 Interference Information ...3 Hearing Aid Compatibility (HAC)...

6 Through the base ...28 Set the answering machine language ...28 Set the answer mode ...

7 LIGHTNING A SIGN “DANGEROUS INSIDE IS A PERSONNEL. N M / K T Industry Canada (I

8 IMPORTANT: Because cordless phones operate on electricity, you should have at least one phone in your home that isn’t cordless, in case the pow

9 Installation Digital Security System Your cordless phone uses a digital security system
